NIR Analyser | PSR-1100f

The PSR-1100f is a compact, field-ready spectroradiometer designed for portable spectral measurements in environmental, agricultural, and research applications.

Video for Spectral Evolution NIR Analyser | PSR-1100f

Lightweight and portable spectroradiometer designed for precise field measurements.

Overview

The PSR-1100f is a lightweight, entry-level spectroradiometer purpose-built for field-based spectral analysis. Weighing just 1.8 kg, it equips researchers and professionals with lab-quality performance anywhere, featuring a removable fibre optic cable and support for a broad range of optional field-of-view lenses and irradiance diffusers.

Key Features

320–1100 nm spectral range
3 nm resolution
Removable/replaceable fibre optic cable with FC connection
Rugged anodised aluminium construction
Keypad & LCD display
Internal memory stores up to 2,500 scans without a computer
Auto exposure & auto dark shutter
Snap-in lithium-ion rechargeable battery
Wireless interface
Shoulder strap for easy mobility

Specifications

Spectral Range	320–1100 nm
Spectral Resolution	3.0 nm @ 600 nm
Spectral Sampling Bandwidth	Data output in 1 nm increments; 781 channels reported
Detector(s)	512-element Si Array
Calibration	Spectral and radiometric calibration using NIST traceable sources
Noise Equivalence Radiance (1.2 m fibre optic)	0.8 × 10^-9 W/cm²/nm/sr @ 700 nm
Software Included	DARWin™ SP Data Acquisition
Power Requirement	7.5 V, 2.5 W
Dimensions (mm)	177.8 × 82.5 × 147.3 mm
Weight	1.8 kg
Interface	USB, Wireless Connection
Minimum Scan Speed	100 ms
Wavelength Reproducibility	0.1 nm
Wavelength Accuracy	±0.5 nm bandwidth
Input	1 m fibre optic (25° field of view); optional fore optics and longer fibre cables available
Operational Temperature Range	0–40 °C
Maximum Radiance	VNIR 2× Solar \| SWIR 10× Solar

Applications

Vegetation studies
Soil analysis
Crop health
Agricultural research
Plant science
Biomass research
Leaf chlorophyll content
Water body studies
Climate studies
Environmental research
Nitrogen level measurements
Forest canopy studies
Ecological research
Ice and glacier research

Available Accessory

Sensaprobe™ with Built-In Camera

To contact Portable Analytical Solutions Pty Ltd about Spectral Evolution NIR Analyser | PSR-1100f use Get a quote.
